Description The C187 is MoTeC’s latest professional level Display Logger featuring an impressively generous, full color screen. It comes standard with 250 MB internal logging memory (can be upgraded to 500 MB) and MoTeC’s world-renowned i2 data analysis software. The vivid 178mm screen (approx. 7″) is high resolution, ultra-bright and anti-reflective for easy reading in direct sunlight. Choose from numerous selectable layouts and configure the channels, labels and colors to suit. An array of 16 full color LEDs is integrated into the unit for use as shift lights, warning lights or other driver alerts. The color, function and intensity of each LED is programmable, allowing users to develop their own unique strategies and sequences. BASIC SPECIFICATIONS Display Screen: Color TFT LCD, anti-reflective Resolution: 800 x 480, anti-aliased graphics Selectable fixed layouts with channel and label configurability 48 user-defined, scrollable message lines with programmable overrides 3 programmable ‘pages’, for example Practice, Warm-Up, Race Logging 250 MB logging memory Logging rates up to 1000 samples per second Fast Ethernet download Includes i2 Standard data analysis software Communications 4 x configurable CAN buses with individually programmable CAN bus speeds One can be used as RS232 Receive Two CAN buses support VIM/SVIM Expanders 2 x dedicated RS232 ports Physical Dimensions 196.2 x 122.5 x 24.9 mm excluding connector Weight 670 g 1 x 79 pin Autosport connector 1 x mini USB port Inputs 10 x analogue voltage inputs (20 with I/O Upgrade) 4 x analogue temperature inputs (8 with I/O upgrade) 4 x digital inputs 2 x switch inputs 4 x speed inputs Outputs 6 x low side outputs PWM or switched operation Internal Sensors 3-axis G sensor Dash temperature sensor Sensor supply voltage Battery voltage Expanders Compatible with MoTeC E888 and E816 Expanders, providing full functionality Compatible with VIM/SVIM Expanders
